10 Blade Gen2 Billet Compressor Wheel with Extended Tapered Tip Technology
Inconel 713c 10 Blade Turbine Wheel with High Horsepower
Cover Integrated with the Speed Sensor Port
Max Air Flow rate: ~90 lb/min, rated @ 1000 FWHP
Stronger Turbine Wheel for High flow
Compressor Wheel: 67*84mm
Turbine Wheel: 74*66mm
Compressor Inlet: 4.0” Hose
Compressor Outlet: 2.5” Hose
Turbine Inlet: T3, T4, or 2.5″ V-Band
Turbine Outlet: XR6 Style 5 Bolt
Oil Feed: -4 AN connect to the Oil Restrictor
Oil Drain: Std T3 Flange
Water In/Outlet: M14*1.5
We highly recommended running water cooling for better durability
Billet actuator with black anodized coating
3 Layer Stainless Steel 5 Bolt Gasket
Based off our popular GTX3584RS series turbo, This is very similar but with the larger 66mm rear wheel it has been proven to make up to 70rwkw more than the Gen 2 versions
PSR3584 GEN3 TURBO comes with stronger turbine wheel for high flow.
